Uninterruptible Power Supply Unit for Universal Use – QUINT-DC-UPS/24DC/40
Signaling
Power In OK
Alarm
Battery Mode
Battery Charge
Green LED
Red LED, ? oating PDT,
30 V AC/DC, maximum; 1 A, maximum
Yellow LED, ? oating PDT,
30 V AC/DC, maximum; 1 A, maximum
Yellow LED, ? ashing, ? oating PDT,
30 V AC/DC, maximum; 1 A, maximum
Approvals/Standards
Electrical equipment of machines
Electrical safety (of IT equipment)
Industrial control equipment
Shipbuilding
Electronic equipment for use in electrical power installations
General Data
Insulation voltage
Input/output to housing:
Mounting position
Degree of protection
Class of protection
MTBF According to IEC 1709 (SN 29 500)
Housing version
Dimensions (W x H x D) default upon delivery
Dimensions (W x H x D) rotated 90°
EN 60 204 (Surge Voltage Category III)
EN 60950/VDE 0805,
UL/C-UL Recognized UL 60 950
UL/C-UL Listed UL 508
Germanischer Lloyd
EN 50 178/VDE 0160
1 kV AC type test
1 kV AC routine test
On a horizontal 35 mm (1.378 in.) DIN rail
EN 60 715
1 kV/1 kV
IP20
II
> 500,000 h
AluNox (AlMg1), closed
(66 x 130 x 125 mm [2.598 x 5.118 x 4.921 in.])
(122 x 130 x 69 mm [4.803 x 5.118 x 2.717 in.])
Weight
Climatic Data
Ambient temperature
Humidity
Vibration
Shock (in all space directions)
Pollution degree
Climatic category
Approximately
Operation/storage
At +25°C (+77°F)
According to IEC 68-2-6
According to IEC 68-2-6
According to EN 50 178
According to EN 60 721
0.9 kg
-25°C to +70°C (-13°F to +158°F)/-40°C to +85°C (-40°F to +185°F)
95%, no condensation
15 - 150 Hz, 2.3g, 90 minutes
30g
2
3K3
c
Conformance With EMC Directive 89/336/EEC
and Low Voltage Directive 73/23/EEC
EMC (Electromagnetic Compatibility)
Noise Immunity According to EN 61000-6-2:
Requirements
EN 61 000-6-2
QUINT-DC-UPS/24DC/40
Noise Immunity According to EN 61000-6-2
? EN 61000-4-2 3)
Electrostatic discharge
Housing
Contact discharge:
Air discharge:
4 kV
8 kV
Level 4
8 kV
15 kV
(ESD)
? EN 61000-4-3 2)
Housing
Level 3
Electromagnetic HF ? eld
Frequency:
Field strength:
80 -1000 MHz
10 V/m
80 - 1000 MHz/1.4 - 2.0 GHz
10 V/m
? EN 61000-4-4 3)
Fast transients (burst):
? EN 61000-4-5 3)
Surge current loads (surge):
Input:
Output:
Signal:
Input:
Output:
Signal:
2 kV
2 kV
1 kV
2 kV
2 kV
0.5 kV
0.5 kV
1 kV
asymmetrical 5)
asymmetrical 5)
asymmetrical 5)
asymmetrical 5)
symmetrical 4)
asymmetrical 5)
symmetrical 4)
asymmetrical 5)
4 kV (Level 4)
2 kV (Level 3)
1 kV (Level 2)
4 kV (Inst. Class 4)
2 kV (Inst. Class 4)
0.5 kV/(Level 1)
0.5 kV/(Level 1)
1 kV/(Level 2)
? EN 61000-4-6 2)
I/O/S:
asymmetrical 5) Level 3
Conducted interference
? EN 61000-4-11 3)
Voltage dips
Frequency:
U 0 :
Input:
0.15 - 80 MHz
10 V
30% reduction of the input voltage
for 0.5 periods
0.15 - 80 MHz
10 V
See Input Data:
Mains buffering
> 20 ms
Criterion B:
Temporary adverse effects on the operating
Symmetrical:
Noise Emission According to EN 50081-2
? Radio interference emission EN 55011
? Radio interference voltage EN 55011
EN 55011 corresponds to CISPR11/EN 55022 corresponds to
CISPR22/EN 61000 corresponds to IEC 1000
2) Criterion A: Normal operating characteristics within the
speci ? ed limits.
3)
Class A 6)
Class A 6)
4)
5) Asymmetrical:
6) Class A:
7) Class B:
EN 55011 (EN 55022) Class B 7)
EN 55011 (EN 55022) Class B 7)
Cable to cable.
Cable to ground.
Industrial applications
Industrial and domestic applications
characteristics that the device corrects
automatically.
PHOENIX CONTACT page 3 of 9
